Photo of wSMA 350GHz band OMT

Image Credit: Ming-JyeWang/SDL Open the larger image The photo-type of planar orthogonal-mode-transducer for wSMA 350 GHz band. The microstripline is fabricated on 25 um thick Si substrate. The size of ring structure is 200 um.
